IVSEC NC691XB PTZ Speed Dome IP Camera - 5MP, 4.3-142MM Motorised LE NS, 25FPS, POE, IP66, 150M IRCCTV Storage Calculatorhttps://www.seagate.com/au/en/video-storage-calculator/ NC691XB Security Camera
With smart tracking, this 5MP image sensor also has long-range IR 150 with a 33 times zoom lens. This camera is very impressive when patrolling large properties | Camera Type | PTZ | | Image Sensor | 1/2.7 Progressive Scan CMOS | | Maximum Video Resolution (Megapixels) | 5MP | | Maximum Video Resolution | 25921944 | | Lens | 4.3mm -142mm (H.FOV: 55 to 2.3) | | Lens Type | Motorised Pan, Tilt and Zoom | | Maximum Night IR Distance (M) | 150 | | Video Compression | H.265+, H.265, H.264+, H.264, MJPEG | | ONVIF depends on firmware version | ONVIF (Profile S/G/T), HTTP API | | IP Rating | IP66 | | Operating Environment | (-)30C to 60C (-22F-149F) Humidity: 90% RH | | Dimensions (H x W x L) mm | 206.4 x 206.4 x 351.8 mm | | Weight (Net) | 3.7 kg | | Accessories | IV2488X | | Power Supply | Power over Ethernet IEEE 802.3at, DC12V | | Power Consumption | <26 W | | Connectors | RJ-45, DC Power Input, Audio In, Audio Out, Alarm in and out. | | Outdoor Use | Yes | | Vandal Resistant | Yes | | Frames Per Second | 25 | | Day/Night Mode | auto | | LED Types | | | Image Enhancement | Flip mode, Brightness, Contrast, Saturation, Sharpness, Hue, Mirror, Angle Flip, Back Light,
White Balance, Shutter, Time Exposure, Defog, 3D Noise Reduction | | Edge Recording microSD/SDHC Card | Micro SD/SDHC Card | | Multiple Streams (encode format) | 4 Streams | | Audio Streaming | Yes input connector for external mic | | Protocols | TCP/IP, UDP, HTTP, HTTPS, DHCP, FTP, RTP/RTSP, DNS, DDNS, NTP, PPPOE, UPNP, SMTP, SMTP, P2P (QR code) | | Intelligent Video (IVS) | Face Recognition, Human &Vehicle Detection, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Crossing Counting, Heat Map | | Cloud option (camera only) | Dropbox | | Software | Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app (QR code) | | Power Over Ethernet | Yes | | Ethernet | Ethernet (10/100 Base-T) | | In The Box | Free Software available (ivsecurity.com.au/support/software), Printed quick user guide, installation template, mounting screws and plugs | | Warranty | 3 Year Warranty |
